Lamp Bulb, 150W Xenon for SS150 Solar Simulator
This 150W Xe bulb is recommended for Sciencetch solar simulator model SS150 only. It is a specially designed lamp to improve the uniformity of the SS150.
$
957.00
In stock
This 150W Xe bulb is recommended for Sciencetch solar simulator model SS150 only. It is a specially designed lamp to improve the uniformity of the SS150.
$
957.00
957.0
USD
Price Valid only in North America
Lamp Bulb, 300W Super Quiet Ozone Free Xenon Arc
A 300W "super quiet" arc lamp replacement bulb.
$
1,103.00
In stock
A 300W "super quiet" arc lamp replacement bulb.
$
1,103.00
1103.0
USD
Price Valid only in North America
Lamp Bulb, XBO 450W OFR
This one of the standard Xenon lamp recommended for the Model 500-500 Power Supply. Although it is rated at 450W, it can be driven at 500W with little effect on its service life. (18V 25A, 1300cd, avg life 2000 hours, length 260mm)
$
868.00
In stock
This one of the standard Xenon lamp recommended for the Model 500-500 Power Supply. Although it is rated at 450W, it can be driven at 500W with little effect on its service life. (18V 25A, 1300cd, avg life 2000 hours, length 260mm)
$
868.00
868.0
USD
Price Valid only in North America
(LH-P-300X) Lamp Housing, Parabolic Reflector, 300W Xe
This lamp housing design is optimized for 300W xenon arc lamps. It features a parabolic reflector.
Lamp Power: 300W
Reflector Type: Parabolic
Lamp Type: Xenon, Ozone free (included)
Power Supply: 601-300 (sold separately)
All Sciencetech LH lamp housings feature a configurable and upgradeable housing capable of being operated in the vertical or horizontal position.
Power and communication are supplied to the housing via a single cable connected to the touchscreen power supply, allowing users to easily and neatly set up the system. A safety interlock prevents power being supplied to the housing while the cover is open, protecting users from electric shock or unwanted light exposure.
A wide variety of collimated or focused output optics is available for use with the LH-series, allowing a full range of sizes, materials, and coatings for optics to best suit the requirement. A wide variety of accessories is also available, including downward-facing stands, optical intensity feedback, and more.
$
2,977.00
In stock
This lamp housing design is optimized for 300W xenon arc lamps. It features a parabolic reflector.
Lamp Power: 300W
Reflector Type: Parabolic
Lamp Type: Xenon, Ozone free (included)
Power Supply: 601-300 (sold separately)
All Sciencetech LH lamp housings feature a configurable and upgradeable housing capable of being operated in the vertical or horizontal position.
Power and communication are supplied to the housing via a single cable connected to the touchscreen power supply, allowing users to easily and neatly set up the system. A safety interlock prevents power being supplied to the housing while the cover is open, protecting users from electric shock or unwanted light exposure.
A wide variety of collimated or focused output optics is available for use with the LH-series, allowing a full range of sizes, materials, and coatings for optics to best suit the requirement. A wide variety of accessories is also available, including downward-facing stands, optical intensity feedback, and more.
$
2,977.00
2977.0
USD
Price Valid only in North America
(XE075) Lamp Bulb, 75W Xenon Arc, Ozone Free
Lamp Type 75W Xenon, Ozone Free
Power 75 W
Current 5.4 A
DC Voltage 14 V
Average Luminance 4000000 cd/mm2
Arc Size 0.25mm x 0.5mm
Average Life 400 h
Diameter 10 mm
Base Anode SFa9-2
Base cathode SFa7.5-2
$
389.00
In stock
Lamp Type 75W Xenon, Ozone Free
Power 75 W
Current 5.4 A
DC Voltage 14 V
Average Luminance 4000000 cd/mm2
Arc Size 0.25mm x 0.5mm
Average Life 400 h
Diameter 10 mm
Base Anode SFa9-2
Base cathode SFa7.5-2
$
389.00
389.0
USD
Price Valid only in North America
(XE150) - 150W Xenon Arc Lamp, Ozone free
Replacement 150W Short arc Xenon lamp.
Vertical or Horizontal operation.
$
460.00
In stock
Replacement 150W Short arc Xenon lamp.
Vertical or Horizontal operation.
$
460.00
460.0
USD
Price Valid only in North America
(XE1600-O) Lamp Bulb, 1600W Xenon Arc, Ozone Free (Osram)
Osram brand Xenon short arc lamp,
Burning Positions: Vertical, horizontal
Envelope Diameter: 46.0 mm
Total Length: 235.0 mm
Length, cathode base to arc: 95.0mm
arc gap length: 3.8mm
Length, base to base: 205mm
Lifespan: 2500 h
Nominal wattage: 1600.00 W
Lamp voltage: 23 V
Nominal current: 65.0 A
Current control range: 50…75 A
Note a XE1600-O lamp may be used in a system previously using an XE1600-U lamp.
Due to the 3.5mm difference in cathode base to arc position, some adjustment in lamp position may be necessary.
$
1,620.00
Osram brand Xenon short arc lamp,
Burning Positions: Vertical, horizontal
Envelope Diameter: 46.0 mm
Total Length: 235.0 mm
Length, cathode base to arc: 95.0mm
arc gap length: 3.8mm
Length, base to base: 205mm
Lifespan: 2500 h
Nominal wattage: 1600.00 W
Lamp voltage: 23 V
Nominal current: 65.0 A
Current control range: 50…75 A
Note a XE1600-O lamp may be used in a system previously using an XE1600-U lamp.
Due to the 3.5mm difference in cathode base to arc position, some adjustment in lamp position may be necessary.
$
1,620.00
1620.0
USD
Price Valid only in North America
(XE2500) Lamp Bulb, 2500W Xenon Arc, Ozone Free
$
2,014.00
In stock
$
2,014.00
2014.0
USD
Price Valid only in North America
(XE3000) Lamp Bulb, 3000W Xenon Arc
A 3000W (3kW) xenon arc lamp bulb replacement.
$
1,925.00
In stock
A 3000W (3kW) xenon arc lamp bulb replacement.
$
1,925.00
1925.0
USD
Price Valid only in North America
(XE300) Lamp Bulb, 300W Xenon Short Arc
A replacement 300W short arc xenon bulb.
Average lifetime = 1000hrs
$
960.00
In stock
A replacement 300W short arc xenon bulb.
Average lifetime = 1000hrs
$
960.00
960.0
USD
Price Valid only in North America
(XE300-UV) Lamp Bulb, 300W Xenon Short Arc, Fused Silica Glass
A 300W xenon short arc lamp bulb, using a fused silica glass envelope. Please note that this lamp produces ozone.
$
1,350.00
In stock
A 300W xenon short arc lamp bulb, using a fused silica glass envelope. Please note that this lamp produces ozone.
$
1,350.00
1350.0
USD
Price Valid only in North America
(XE500) Lamp Bulb, 500W Xenon Arc, Ozone Free
A 500W Xenon arc lamp.
Nominal Current 28.0A
Nominal Voltage: 17.0V
Anode base SFa16-8 (8mm stud)
Cathode base SFa15-10 (10mm stud)
$
895.00
In stock
A 500W Xenon arc lamp.
Nominal Current 28.0A
Nominal Voltage: 17.0V
Anode base SFa16-8 (8mm stud)
Cathode base SFa15-10 (10mm stud)
$
895.00
895.0
USD
Price Valid only in North America
(XE6500) Lamp Bulb, 6500W Xenon Arc, Ozone Free
6500W Xenon arc lamp
Ozone Free
Compatible with Sciencetech Ultra-High Power Lamp Houses.
Nominal Wattage 6500 W
Nominal Voltage 39 V
Current (A) 165 A
Current Control Range (A) 133-173 A
Physical attributes
Base Anode SFAx30-14
Base Cathode SFa30-7.9
$
2,826.00
In stock
6500W Xenon arc lamp
Ozone Free
Compatible with Sciencetech Ultra-High Power Lamp Houses.
Nominal Wattage 6500 W
Nominal Voltage 39 V
Current (A) 165 A
Current Control Range (A) 133-173 A
Physical attributes
Base Anode SFAx30-14
Base Cathode SFa30-7.9
$
2,826.00
2826.0
USD
Price Valid only in North America
