Accessories / Parts

This accessory can be added to an XLH-style lamp housing to vent ozone produced by UV-enhanced xenon arc lamp sources. This product is compatible with all XLH-series housings for 500-1600 W xenon short arc lamps.

Contact for Pricing

This accessory can be added to an LH-style lamp housing to vent ozone produced by UV-enhanced xenon arc lamp sources. This product is compatible with all LH-series housings for 75-300 W xenon short arc lamps.

Contact for Pricing

6500W Xenon arc lamp
Ozone Free
Compatible with Sciencetech Ultra-High Power Lamp Houses.

Nominal Wattage 6500 W
Nominal Voltage 39 V
Current (A) 165 A
Current Control Range (A) 133-173 A

Physical attributes
Base Anode SFAx30-14
Base Cathode SFa30-7.9

$ 2,826.00

$ 2,014.00

Sciencetech's PS-XE500 to PS-XE1600 series power supplies are designed to work with Sciencetech XLH series lamp houses. Includes a USB to serial adapter.
The PS-XE1600-A-T is designed to power 1600 W xenon and mercury-xenon arc lamps. The PS-XE1600-A-T power supply is CE compliant.
This power supply includes a touchscreen interface and several useful built in components:
- Lamp life timer
- Powers and controls Sciencetech XLH lamp house fans
- Shutter and exposure controller
- RS232 Computer Control
- Safety interlock

Power Requirements
200-240 VAC input, 12.1-9.0 A, 50/60 Hz, Fused 15 A

This system includes 1 IEC 60320 C19 compatible power cables. Region-specific version must be selected at the time of placing an order (see product 491-9003).

$ 7,100.00

Sciencetech's PS-XE500 to PS-XE1600 series power supplies are designed to work with Sciencetech XLH series lamp houses. Includes a USB to serial adapter.
The PS-XE1000-A-T is designed to power 1000 W xenon and mercury-xenon arc lamps. The PS-XE1000-A-T power supply is CE compliant.
This power supply includes a touchscreen interface and several useful built in components:
- Lamp life timer
- Powers and controls Sciencetech XLH lamp house fans
- Shutter and exposure controller
- RS232 Computer Control
- Safety interlock

Power Requirements
200-240 VAC input, 7.5-6.3 A, 50/60 Hz, Fused 15 A

This system includes 1 IEC 60320 C19 compatible power cables. Region-specific version must be selected at the time of placing an order (see product 491-9003).

$ 6,880.00

Sciencetech's PS-XE500 to PS-XE1600 series power supplies are designed to work with Sciencetech XLH series lamp houses. Includes a USB to serial adapter.
The PS-XE500-A-T is designed to power 500 W xenon and mercury-xenon arc lamps. The PS-XE500-A-T power supply is CE compliant.
This power supply includes a touchscreen interface and several useful built in components:
- Lamp life timer
- Powers and controls Sciencetech XLH lamp house fans
- Shutter and exposure controller
- RS232 Computer Control
- Safety interlock

Power Requirements
100-240 VAC input, 9.1-3.8 A, 50/60 Hz
This system includes 1 IEC 60320 C13 compatible power cable. Region-specific version must be selected at the time of placing an order (see product 491-9001).

$ 6,805.00

This lamp housing design is optimized for 300 W xenon arc lamps. It features a parabolic reflector producing a collimated beam with a diameter of ~66 mm (exit clear aperture of the lamp house).

Lamp Power: 300 W
Reflector Type: Parabolic
Lamp Type: Xenon, Ozone free (included)
Power Supply: PS-XE300-A-T or PS-XE300-A-M (sold separately)

All Sciencetech LH lamp housings feature a configurable and upgradeable housing capable of being operated in the vertical or horizontal position.

Power and communication are supplied to the housing via a single cable connected to the touchscreen power supply, allowing users to easily and neatly set up the system. A safety interlock prevents power being supplied to the housing while the cover is open, protecting users from electric shock or unwanted light exposure.

A wide variety of collimated or focused output optics is available for use with the LH-series, allowing a full range of sizes, materials, and coatings for optics to best suit the requirement. A wide variety of accessories is also available, including downward-facing stands, optical intensity feedback, and more.

$ 2,977.00

Sciencetech's touchscreen 75 W xenon arc lamp power supply designed for use with Sciencetech's LH- series lamp housing.
This power supply features a 7W2 connection so that only one cable is required to supply all lamp power and communication to the lamp housing. This power supply also has a shutter connection and RS232 connection for electronic control of a shutter or computer control of the power supply if those optional accessories are purchased.

PS-XE075-A-T power supplies accept 110-240 VAC input. Includes a USB to serial adapter.
This system includes 1 IEC 60320 C13 compatible power cable. Region-specific version must be selected at the time of placing an order (see product 491-9001).

Features
-single 7W2 connection for lamp power, cooling, and communication to lamp house
-easy-to-use touchscreen interface
-shutter and exposure control (if electronic shutter upgrade is ordered)
-lamp start and time log
-safety interlocks

Optional Upgrades
-RS232 computer control with GUI
-temperature monitor
-remote lamp status monitoring
-auto lamp starting

$ 2,767.00

Sciencetech's touchscreen 150 W xenon arc lamp power supply designed for use with Sciencetech's LH- series lamp housing.
This power supply features a 7W2 connection so that only one cable is required to supply all lamp power and communication to the lamp housing. This power supply also has a shutter connection and RS232 connection for electronic control of a shutter or computer control of the power supply if those optional accessories are purchased.

PS-XE150-A-T power supplies accept 110-240 VAC input.
This system includes 1 IEC 60320 C13 compatible power cable. Region-specific version must be selected at the time of placing an order (see product 491-9001).
Includes a USB to serial adapter.

Features
-single 7W2 connection for lamp power, cooling, and communication to lamp house
-easy-to-use touchscreen interface
-shutter and exposure control (if electronic shutter upgrade is ordered)
-lamp start and time log
-safety interlocks

Optional Upgrades
-RS232 computer control with GUI
-temperature monitor
-remote lamp status monitoring
-auto lamp starting

$ 3,460.00

Sciencetech's touchscreen 300 W xenon arc lamp power supply designed for use with Sciencetech's LH- series lamp housing.
This power supply features a 7W2 connection so that only one cable is required to supply all lamp power and communication to the lamp housing. This power supply also has a shutter connection and RS232 connection for electronic control of a shutter or computer control of the power supply if those optional accessories are purchased.

PS-XE300-A-T power supplies accept 110-240 VAC input.

This system includes 1 IEC 60320 C13 compatible power cable. Region-specific version must be selected at the time of placing an order (see product 491-9001).

Includes a USB to serial adapter.

Features
-single 7W2 connection for lamp power, cooling, and communication to lamp house
-easy-to-use touchscreen interface
-shutter and exposure control (if electronic shutter upgrade is ordered)
-lamp start and time log
-safety interlocks
-RS232 software GUI included, shown below

Optional Upgrades
-temperature monitor
-remote lamp status monitoring
-auto lamp starting

$ 3,460.00

Replacement 150W Short arc Xenon lamp.
Vertical or Horizontal operation.

$ 460.00

A 300W xenon short arc lamp bulb, using a fused silica glass envelope. Please note that this lamp produces ozone.

$ 1,350.00

A 3000W (3kW) xenon arc lamp bulb replacement.

$ 1,925.00

A replacement 300W short arc xenon bulb.
Average lifetime = 900hrs

$ 960.00

Osram brand Xenon short arc lamp,
Burning Positions: Vertical, horizontal
Envelope Diameter: 46.0 mm
Total Length: 235.0 mm
Length, cathode base to arc: 95.0 mm
arc gap length: 3.8 mm
Length, base to base: 205 mm
Lifespan: 2500 h
Nominal wattage: 1600.00 W
Lamp voltage: 23 V
Nominal current: 65.0 A
Current control range: 50-75 A

Note a XE1600-O lamp may be used in a system previously using an XE1600-U lamp.
Due to the 3.5 mm difference in cathode base to arc position, some adjustment in lamp position may be necessary.

$ 1,620.00

This 150W Xe bulb is recommended for Sciencetch solar simulator model SS150 only. It is a specially designed lamp to improve the uniformity of the SS150.

$ 957.00
