Grating Selection
Diffraction gratings are surfaces with a periodic structure used to diffract broad spectrum light at different angles according to wavelength, allowing the component wavelengths
Grating selection is a crucial part of building a monochromator. Each ruled or holographic grating is designed to diffract light most efficiently over a specific band of wavelengths.
This tool allows you to compare efficiency curves for different gratings that Sciencetech offers. These curves are for comparison purposes only [1] .
Currently Comparing:
Use the filters and table below to select gratings and add them to the chart.
Type
All Plane Ruled Plane Holographic Concave Holographic Other
Nominal Blaze (nm)
All < 400 400 - 699 700 - 1999 2000 - 4999 ≥ 5000
Groove Density (l/mm)
All < 300 300 - 599 600 - 899 900 - 1199 ≥ 1200
Size (mm)
All 30 × 30 32 × 32 50 × 50 52 × 52 64 × 64 84 × 84 102 × 102
82 gratings matching your criteria
SKU
Type
Size (mm)
Blaze (nm)
Groove (l/mm)
Compare
630-0087
Plane Ruled
30×30
400
1200
Compare
630-0088
Plane Ruled
30×30
800
830
Compare
630-0089
Plane Ruled
30×30
250
1200
Compare
630-0090
Plane Ruled
30×30
300
1200
Compare
630-0091
Plane Ruled
30×30
500
1200
Compare
630-0092
Plane Ruled
30×30
1250
600
Compare
630-0093
Plane Ruled
30×30
1000
600
Compare
630-0094
Plane Ruled
30×30
500
600
Compare
630-0096
Plane Ruled
30×30
2000
300
Compare
631-0001
Plane Holographic
50×50
250
1200
Compare
631-0002
Plane Ruled
50×50
240
1800
Compare
631-0003
Plane Holographic
50×50
500
1800
Compare
631-0005
Plane Holographic
50×50
250
2400
Compare
631-0010
Plane Ruled
50×50
400
1200
Compare
631-0011
Plane Ruled
50×50
300
1200
Compare
631-0012
Plane Ruled
50×50
2000
300
Compare
631-0013
Plane Ruled
50×50
500
300
Compare
631-0014
Plane Ruled
50×50
750
600
Compare
631-0019
Plane Ruled
50×50
750
1200
Compare
631-0020
Plane Ruled
50×50
1600
600
Compare
631-0021
Plane Ruled
50×50
500
1800
Compare
631-0024
Plane Ruled
50×50
1000
1200
Compare
631-0025
Plane Ruled
50×50
1000
600
Compare
631-0027
Plane Holographic
50×50
250
1200
Compare
631-0028
Plane Ruled
50×50
1250
600
Compare
631-0032
Plane Ruled
50×50
500
600
Compare
631-0033
Plane Ruled
50×50
250
1200
Compare
631-0037
Plane Ruled
50×50
500
1200
Compare
631-0040
Plane Ruled
50×50
400
600
Compare
631-0041
Plane Ruled
50×50
2000
300
Compare
631-0051
Plane Ruled
50×50
1200
830
Compare
631-0055
Plane Ruled
50×50
500
150
Compare
631-0056
Plane Ruled
50×50
1000
300
Compare
631-0057
Plane Ruled
50×50
4000
300
Compare
631-0058
Plane Ruled
50×50
12000
120
Compare
631-0062
Plane Ruled
50×50
1000
600
Compare
631-0070
Plane Ruled
50×50
800
830
Compare
631-0075
Plane Ruled
50×50
250
1200
Compare
631-0080
Plane Holographic
50×50
500
1200
Compare
631-0082
Plane Ruled
50×50
150
1200
Compare
632-0006
Plane Holographic
64×64
500
1800
Compare
632-0015
Plane Ruled
64×64
500
1200
Compare
632-0016
Plane Ruled
64×64
750
1200
Compare
632-0017
Plane Ruled
64×64
1000
1200
Compare
632-0018
Plane Ruled
64×64
400
1200
Compare
632-0046
Plane Ruled
64×64
500
150
Compare
632-0047
Plane Ruled
64×64
500
300
Compare
632-0083
Plane Ruled
64×64
250
1200
Compare
632-0085
Plane Ruled
64×64
500
1200
Compare
633-0026
Plane Ruled
84×84
500
1200
Compare
633-0050
Plane Ruled
84×84
800
600
Compare
633-0053
Plane Ruled
84×84
650
600
Compare
633-0073
Plane Ruled
84×84
300
1200
Compare
634-0004
Plane Ruled
102×102
300
1200
Compare
634-0007
Plane Ruled
102×102
422
300
Compare
634-0029
Plane Holographic
102×102
250
2400
Compare
634-0030
Plane Ruled
102×102
600
1200
Compare
634-0059
Plane Holographic
102×102
850
900
Compare
634-0065
Plane Ruled
102×102
500
1200
Compare
634-0066
Plane Ruled
102×102
500
600
Compare
634-0067
Plane Ruled
102×102
500
300
Compare
634-0068
Plane Holographic
102×102
250
1200
Compare
634-0069
Plane Holographic
102×102
700
1200
Compare
634-0076
Plane Holographic
102×102
620
1150
Compare
634-0077
Plane Holographic
102×102
450
1800
Compare
634-0078
Plane Holographic
102×102
650
600
Compare
634-0079
Plane Ruled
102×102
550
900
Compare
634-0093
Plane Ruled
102×102
12000
75
Compare
634-0094
Plane Ruled
102×102
1200
300
Compare
634-0095
Plane Ruled
102×102
8300
120
Compare
635-0008
Concave Holographic
32×32
450
1200
Compare
635-0009
Concave Holographic
32×32
250
1200
Compare
635-0022
Concave Holographic
32×32
600
Compare
635-0035
Concave Holographic
32×32
800
Compare
635-0038
Concave Holographic
32×32
350
1200
Compare
637-0043
Specialty - Ion Etched
50×50
3100
450
Compare
637-0044
Specialty - Ion Etched
50×50
5400
300
Compare
637-0052
Specialty - Ion Etched
50×50
5400
150
Compare
637-0071
Specialty - Ion Etched
50×50
10000
75
Compare
637-0072
Specialty - Ion Etched
50×50
5500
300
Compare
637-0086
Plane Ruled
52×52
800
600
Compare
