Workstation Solar Simulators

Class: AAA
Target Size: 125mm x 125 mm
Working Distance: 300mm
550W Xe Arc Lamp Included
Integrated touch screen control unit
RS232 interface and software for remote operation included
Includes air mass filter AM1.5G (160-8023) and computer-controlled shutter.

$ 30,750.00

Class: AAA (ASTM)
Target Size: 300mm x 300 mm
Working Distance: 650mm
Integrated touch screen control unit
RS232 interface and software for remote operation included
Includes air mass filter AM1.5G (160-8023) and computer-controlled shutter.

$ 70,125.00

Class: AAA
Target Size: 250mm x 250 mm
Working Distance: 650mm
1600W Lamp Included
Integrated touch screen control unit
RS232 interface and software for remote operation included
Includes air mass filter AM1.5G (160-8023) and computer-controlled shutter.

$ 58,600.00

Class: AAA
Target Size: 200mm x 200 mm
Working Distance: 575mm
1000W Lamp Included
Integrated touch screen control unit
RS232 interface and software for remote operation included
Includes air mass filter AM1.5G (160-8023) and computer-controlled shutter.

$ 40,490.00

Class: AAA
Target Size: 150mm x 150 mm
Working Distance: 500mm
500W Lamp Included
Integrated touch screen control unit
RS232 interface and software for remote operation included
Includes air mass filter AM1.5G (160-8023) and computer-controlled shutter.

$ 29,750.00

Class: AAA
Target Size: 100mm x 100 mm
Working Distance: 300mm
300W Lamp Included
Integrated touch screen control unit
RS232 interface and software for remote operation included
Includes air mass filter AM1.5G (160-8023) and computer-controlled shutter.

$ 26,800.00

Class: AAA
Target Size: 75mm x 75 mm
Working Distance: 225 mm
300W Lamp Included
Integrated touch screen control unit
RS232 interface and software for remote operation included
Includes air mass filter AM1.5G (160-8023) and computer-controlled shutter.

$ 18,506.00

Class: AAA
Target Size: 60mm × 60mm
Working Distance: 300mm
Spectral Range: 350nm - 1400nm
Lamp: 300W
Available AM Filtering: AM1.5G, AM1.5D (AM0 not available)
Power Supply 601-300 included

The SL-60A-WS is a Class AAA solar simulator with an integrated testing workstation, ideal for the benchtop. The system includes arc lamp housing, bulb, integrated power supply with igniter, adjustable testing stage, accessories rack, automatic shutter, beam turner, 2-position filter holder, and testing report. The beam is projected vertically by default or the end plate can be removed for horizontal operation.

Available air mass filters include AM1.5G and AM1.5D. AM0 is not available for this model due to limited UV output. Other filters such as dichroic filters and bandpass filters are available for further modification of the spectrum. Filters are sold separately; please specify which filters should be sent with the solar simulator when ordering.

Conformity with IEC and JIS standards for spectral matching, non-uniformity, and temporal instability is available. Please contact your Sciencetech Technical Representative for details.

Please speak with your authorized Sciencetech Technical Sales Staff for further details and a full range of options.

$ 14,000.00

Class: AAA
Target Size: 50mm × 50mm (up to 2 Suns)
(70mm × 60mm Class B at 1 Sun)
Working Distance: 250mm (typical)
Spectral Range: 350nm - 1400nm
Lamp: 300W
Available AM Filtering: AM1.5G, AM1.5D (AM0 not available)
Power Supply 601-300 included

The SL-50A-WS is a Class AAA solar simulator with an integrated testing workstation, ideal for the benchtop. The system includes arc lamp housing, bulb, integrated power supply with igniter, adjustable testing stage, accessories rack, automatic shutter, beam turner, 2-position filter holder, and testing report. The beam is projected vertically by default or the end plate can be removed for horizontal operation.

Available air mass filters include AM1.5G and AM1.5D. AM0 is not available for this model due to limited UV output. Other filters such as dichroic filters and bandpass filters are available for further modification of the spectrum. Filters are sold separately; please specify which filters should be sent with the solar simulator when ordering.

Conformity with IEC and JIS standards for spectral matching, non-uniformity, and temporal instability is available. Please contact your Sciencetech Technical Representative for details.

Please speak with your authorized Sciencetech Technical Sales Staff for further details and a full range of options.

$ 12,965.00

Class: AAA
Target Size: 38mm × 38mm
Working Distance: 250mm
Spectral Range: 350nm - 1400nm
Lamp: 150W
Available AM Filtering: AM1.5G, AM1.5D (AM0 not available)
Power Supply 601-150 included

The SL-38A-WS is a Class AAA solar simulator with an integrated testing workstation, ideal for the benchtop. The system includes arc lamp housing, bulb, integrated power supply with igniter, adjustable testing stage, accessories rack, automatic shutter, beam turner, 2-position filter holder, and testing report. The beam is projected vertically by default or the end plate can be removed for horizontal operation.

Available air mass filters include AM1.5G and AM1.5D. AM0 is not available for this model due to limited UV output. Other filters such as dichroic filters and bandpass filters are available for further modification of the spectrum. Filters are sold separately; please specify which filters should be sent with the solar simulator when ordering.

Conformity with IEC and JIS standards for spectral matching, non-uniformity, and temporal instability is available. Please contact your Sciencetech Technical Representative for details.

Please speak with your authorized Sciencetech Technical Sales Staff for further details and a full range of options.

$ 11,950.00
