Accessories / Parts

Wavelength range: 400-1600nm
Dispersion: 16nm/mm (When used with 9030 monochromator)

$ 1,593.00

This is a single fixed width slit for Sciencetech's 9030 monochromators. It can also be used with any other model monochromator, but requires a SS-F slit holder (120-9046) for each input/output. Multiple slits can be exchanged using a single slit holder.
Please note that the Model 9030 monochromator already includes a pair of removable fixed width slits.
The slit height is 8mm. The slit width is 100μm.

$ 250.00

This 16bit data aquisition module features 3 analog inputs via BNC connectors. The data aquisition board is 16Bit and can measure a single channel up to 50Ks/S. An additional BNC connector for a multi-purpose digital input/output can be used to time measurements and/or send signals to external hardware such as a high speed shutter.

This module includes 1 BNC cable and 1 USB cable so that it is ready to interface with a single channel detector such as a PMT or UVSi photodiode detector (sold seperatley). For spectroscopy systems the Sci-Spec Windows application software to interface with a Windows Based PC is required and is sold separately.

multi-channel dataaquisition is possible using SciSpec software, if this option is required please speak to a Sciencetech technical sales representative.

$ 901.00

This 12-bit data aquisition module features 3 analog inputs via BNC connectors. The data aquisition board is 12Bit and can measure a single channel up to 50Ks/S. An additional BNC connector for a trigger input can be used to time measurements and/or send signals to external hardware such as a high speed shutter.

This module includes 1 BNC cable and 1 USB cable so that it is ready to interface with a single channel detector such as a PMT or UVSi photodiode detector (sold seperatley). For spectroscopy systems the Sci-Spec Windows application software to interface with a Windows Based PC is required and is sold separately.

This module is wired for single ended input for +/-10V input range. This module can be wired for differential inputs upon request.
For most single channel data aquisition options where differential inputs are not required the SCI-DAS-12USB-LS option is a suitable and economical option.

multi-channel dataaquisition is possible using SciSpec software, if this option is required please speak to a Sciencetech technical sales representative.

$ 706.00

A 6" x 6" (152.4 mm x 152.4 mm) air mass filter specifically designed for Sciencetech's Fresnel Solar Simulator Series, including filter holder. The AM0 spectrum simulates the solar spectrum just outside Earth’s atmosphere, where there is very little atmosphere-related absorption of solar radiation. This is generally used for space applications.

$ 4,133.00

SciSpec is a fully featured Windows application specifically designed to control Sciencetech stepping monochromators. SciSpec is designed to control and coordinate the operation of Sciencetech modular spectroscopy components. These include:
• stepping monochromators
• motorized filter wheels for a long pass, bandpass, short pass, or neutral density filtering
• motorized beam path selection mirrors
• beam line modulators such as motorized iris or chopper
• detectors and data acquisition components such as A/D boards, lock-in amplifiers, and source meters.
• linear diode arrays
• sources such as research arc lamps, LED, and incandescent light sources

Generally, all the components in a modular spectroscopy system must be configured by wavelength to optimize the system operation. SciSpec stores and reads system configurations to provide an optimized system operation and user experience.

Requires Windows 7/10 64bit operating system

$ 610.00

28 mm (1-1/8 inch) transmission mode S-1 photocathode, Side-on type.
Spectral Response: 400 - 1200nm
Wavelength of Maximum Response: 800nm
Minimum Effective Area (HxW): 16 x 18

Quantum Efficiency (at 25 degrees): 0.04% (Typical)
Anode Dark Current (after 30 min storage in darkness): 350 (typical), 1000 (max) nA

$ 1,946.00

Multialkali high sensitivity side-on PMT
Spectral range: 185-900 nm,
Peak sensitivity wavelength: 400nm
Glass UV Envelope

Photocathode Area Size 8 x 24 mm
Photocathode Material Multialkali
Window Material UV glass
Dynode Structure Circular-cage
Anode to Cathode Voltage 1250 V
Average Anode Current 0.1 mA
Anode to Cathode Supply Voltage 1000 V
Luminous Sensitivity Min. 140 μA/lm
Luminous Sensitivity Typ. 250 μA/lm
Radiant Sensitivity Typ. 74 mA/W
Anode Luminous Sensitivity Min. 400 A/lm
Anode Luminous Sensitivity Typ. 2500 A/lm
Anode Radiant Sensitivity Typ. 7.4e5 A/W
Anode Dark Current (after 30min.) Typ. 3 nA
Anode Dark Current (after 30min.) Max. 50 nA
Time Response Rise Time Typ. 2.2 ns
Time Response Transit Time Typ. 22 ns

$ 1,130.00

Osram brand Xenon short arc lamp,
Burning Positions: Vertical, horizontal
Envelope Diameter: 46.0 mm
Total Length: 235.0 mm
Length, cathode base to arc: 95.0mm
arc gap length: 3.8mm
Length, base to base: 205mm
Lifespan: 2500 h
Nominal wattage: 1600.00 W
Lamp voltage: 23 V
Nominal current: 65.0 A
Current control range: 50…75 A

Note a XE1600-O lamp may be used in a system previously using an XE1600-U lamp.
Due to the 3.5mm difference in cathode base to arc position, some adjustment in lamp position may be necessary.

$ 1,620.00

This 150W Xe bulb is recommended for Sciencetch solar simulator model SS150 only. It is a specially designed lamp to improve the uniformity of the SS150.

$ 957.00

This filter is part of Sciencetech's standard "Order Sorting Filter Set". It can be ordered separately if required.
Please see the technical datasheet for additional information.

$ 20.00

Wavelength range: 300-1200nm
Dispersion: 12nm/mm (When used with 9030 monochromator)

$ 1,450.00

.

$ 730.00

.

$ 500.00

.

$ 4,000.00

Holographic Grating
2400 lines per mm
Blazed at 250nm
Substrate Size: 110 x 110 x 16mm
Ruled Area: 102 x 102mm

$ 5,500.00

.

$ 500.00

.

$ 730.00

.

$ 3,500.00

.

$ 730.00
